Capabilities

We Beat Expectations

Our Equipment

We maintain our equipment to rigorous industry standards. Our years of experience with these machines ensure a quality product delivered on-time and on-budget. Our leadership and shop crew have experience on everything from decades old, manually calibrated tools to the latest in program-automated machining.

What We Do

We manufacture close tolerance machined parts for the transportation, energy, aerospace, and automotive industries. We offer reverse engineering and 3 dimensional machining. We refurbish control and flow valves for any fluid control system.

content service

Mills

  • Hardinge V480 APC Vertical Mill (NEW)
  • Fadal 60-30 Mill Center with 4th Axis
  • Fadal 40-16 Mill Center with 4th Axis
  • Fadal 40-20 Mill Center with 4th Axis
  • Fadal 30-16 Mill Center with 4th Axis
  • Fadal VMC-20 Mill Center
  • Fadal VMC-40-16 Mill Center

Largest cube: 60" x 30" x 30"
4th Axis Capabilities

Lathes

  • Okuma Genos L400 x 500
  • Okuma LB400 EXII (NEW) (with 15 inch chuck)
  • Mazak Quick Turn 20 HP
  • Okuma L470 Captain (with 15 inch chuck)
  • Okuma Genos L300MW (with live tooling and sub spindle)

Maximum Diameter: 24.00"
Maximum Length: 60.00"

Materials

  • All Steels
  • All Plastics
  • Non-Ferrous Materials

Capabilities

  • CNC Milling
  • CNC Turning
  • Control Valve Rebuild
  • Assembly
  • Prototyping
  • 3D Machining
  • Reverse Engineering
  • 10-1,000pc Contracts

Inspection Equipment

  • Numerex C.M.M.
    New software retrofit 2007
  • Complete Micrometers to 24.00"
  • Clausing Optical Comparator
    14.00" Capacity
  • Bore Mics to 8.00"
  • Pratt & Whitney Supermicrometer
    Model B, 10" capacity

Support Equipment

  • W.F. Wells 9-14 CNC Saw 2007
  • Do-All Automatic Saw
  • Millport Series 1 Mill
  • Kasto 10" Automatic Cold Saw
  • Sunnen Precision Honing Machine
  • Webb 8" Engine Lathe
  • BOS Surface Grinder (2000)

Support Software

  • Solid Works
  • Surfcam
  • AutoCAD

Diversified Manufacturing Systems

421 West 12th Street
Erie, PA 16501
